Product Details:
|
| Connector: | LCAPC Or Customized | Fiber Type: | SM G657A1 Or Customized |
|---|---|---|---|
| Jacket: | Tight Buffer Or Loose Tube Or Semi-tight | Jacket Color: | Blue |
| Bend Radius: | 15mm F | Insertion Loss: | <0.2dB (typical); <0.3dB (Maximum) |
| High Light: | loose tube jacket fiber optic pigtail,rj45 fiber optic pigtail,rj45 pigtail for fiber optic cable |
||
0.9mm LC PC Fiber Optic Pigtail LSZH SM G657A1 G657A2 G657B3 Bend Intensive
Description
SM LC PC fiber optic pigtail connectors feature the RJ-45 style interface with low insertion loss and low back reflection; it is with high precision alignment and is widely used all over the world. The connector is with a 1.25mm O.D zirconia ceramic ferrule; saving 50% space compared to SC fiber optic pigtail. It is compliant to Telcordia, EIA/TIA and IEC standards.
ANC is good at OEM and ODM production of 0.9mm fiber optic pigtail, 12 color fiber optic pigtail, multi-core bundle fiber optic pigtail, armored fiber optic pigtail, waterproof fiber optic pigtail, etc
Specification
Compact, pull-proof design
RJ-45 style interface
Low insertion loss and low back reflection
Different cable color optional
The jacket can be tight buffer, easy-strip or semi-tight;
Usage
FTTH Network
Optical termination box
Fiber Optic Telecommunication
Fiber Distribution Frame
Gigabit Ethernet
Active Device Termination
Premise Installations
Technical Data
| Item | Parameter | |
| Single-mode | Multi-mode | |
| Insertion Loss | ≤0.3dB | |
| Return Loss | ≥50 dB (PC), ≥60 dB (APC) | |
| Repeatability | ≤0.1dB | |
| Durability | 0.2dB Max. 1000 mattings | |
| Operating Temperature | -40℃~+85℃ | |
| Storage Temperature | -40℃~+85℃ | |
Advantages Of Fiber Optic Splitter
1. Adopt high strength stainless steel, pass salt spray test
2. Ferrule core is less than 0.2um
3. Adopt 100% new raw material, ROHS compliance
4. Low Insertion loss
5. Low PDL Compact Design
6. Good channel-to-channel uniformity
7. Wide Operating Wavelength: from 1260nm to 1650nm
8. Wide Operating Temperature: from -40℃ to 85℃
